MJWI25-24S12
MINMAX
MJWI25-24S12
FEATURES
►Smallest Encapsulated 25W Converter
►Ultra-compact 1" X 1" Package
►Ultra-wide 4:1 Input Voltage Range
►Fully Regulated Output Voltage
►Excellent Efficiency up to 90%
►I/O Isolation 1500 VDC
►Operating Ambient Temp. Range -40℃ to +80℃
►No Min. Load Requirement
►Overload/Voltage and Short Circuit Protection
►Remote On/Off Control, Output Voltage Trim
►Shielded Metal Case with Insulated Baseplate
►UL/cUL/IEC/EN 62368-1(60950-1) Safety Approval & CE Marking
PRODUCT OVERVIEW
The MINMAX MJWI25 series is the latest range of a new generation of high performance DC-DC converter modules with very high power density. The product offers fully 25W in a shielded metal package with dimensions of just 1.0"x1.0"x0.4". All models provide ultra-wide 4:1 input range and tightly regulated output voltage. State-of-the-art circuit topology provides a very high efficiency up to 90% which allows an operating temperature range of -40℃ to +80℃. These converters are qualified for demanding applications in battery operated equipment, instrumentation, data communication, industrial and many other space critical applications.
FEATURES
►Smallest Encapsulated 25W Converter
►Ultra-compact 1" X 1" Package
►Ultra-wide 4:1 Input Voltage Range
►Fully Regulated Output Voltage
►Excellent Efficiency up to 90%
►I/O Isolation 1500 VDC
►Operating Ambient Temp. Range -40℃ to +80℃
►No Min. Load Requirement
►Overload/Voltage and Short Circuit Protection
►Remote On/Off Control, Output Voltage Trim
►Shielded Metal Case with Insulated Baseplate
►UL/cUL/IEC/EN 62368-1(60950-1) Safety Approval & CE Marking
PRODUCT OVERVIEW
The MINMAX MJWI25 series is the latest range of a new generation of high performance DC-DC converter modules with very high power density. The product offers fully 25W in a shielded metal package with dimensions of just 1.0"x1.0"x0.4". All models provide ultra-wide 4:1 input range and tightly regulated output voltage. State-of-the-art circuit topology provides a very high efficiency up to 90% which allows an operating temperature range of -40℃ to +80℃. These converters are qualified for demanding applications in battery operated equipment, instrumentation, data communication, industrial and many other space critical applications.
