MAU102
MINMAX
MAU102
FEATURES
►Industrial Standard SIP-7 Package
►Unregulated Output Voltage
►I/O Isolation 1000 VDC
►Operating Ambient Temp. Range -40℃ to +85℃
►UL/cUL/IEC/EN 60950-1 Safety Approval
PRODUCT OVERVIEW
The MINMAX MAU100 series is a range of 1W DC-DC converters in a small SIP Package featuring I/O isolation of 1000VDC. An excellent efficiency allows an operating temperature range of –40℃ to +85℃. These converters offer an economical solution for many applications where a voltage has to be isolated i.e for noise reduction, ground loop elimination, digital interfaces or for board level power distribution.
FEATURES
►Industrial Standard SIP-7 Package
►Unregulated Output Voltage
►I/O Isolation 1000 VDC
►Operating Ambient Temp. Range -40℃ to +85℃
►UL/cUL/IEC/EN 60950-1 Safety Approval
PRODUCT OVERVIEW
The MINMAX MAU100 series is a range of 1W DC-DC converters in a small SIP Package featuring I/O isolation of 1000VDC. An excellent efficiency allows an operating temperature range of –40℃ to +85℃. These converters offer an economical solution for many applications where a voltage has to be isolated i.e for noise reduction, ground loop elimination, digital interfaces or for board level power distribution.
